Refrigerated Air Dryer IDF □E/F/D
Air Preparation Equipment » Air Dryers
-
* The refrigerated air dryer IDF22E to IDF75E series is to be discontinued.
Please consider selecting an IDF60 to 90 series refrigerated air dryer as a
substitute.
Discontinuation date
IDF22E/IDFA22E: Discontinued
IDF37E/IDFA37E: Scheduled to be discontinued as of the end of
March 2024
IDF55E/IDFA55E: Scheduled to be discontinued as of the end of
September 2024
IDF75E/IDFA75E: Scheduled to be discontinued as of the end of
September 2024
Safety Instructions Air Preparation Equipment/Precautions
Model Selection Guide/Quick Reference Guide Green Procurement (RoHS) Proposal for the Use of a Separate Refrigerated Air Dryer
Model Selection Guide/Quick Reference Guide Green Procurement (RoHS) Proposal for the Use of a Separate Refrigerated Air Dryer
| Series | Rated inlet condition | Air flow capacity (m3/min[ANR]) 50 Hz | Air flow capacity (m3/min[ANR]) 60 Hz | Applicable air compressor (kW) | Refrigerant | Port size | Compressor output |
|---|---|---|---|---|---|---|---|
| IDF1E | 35℃ 0.7 MPa | 0.1 | 0.12 | 0.75 | R134a （HFC） | Rc3/8 | Less than 7.5kw |
| IDF2E | 35℃ 0.7 MPa | 0.2 | 0.235 | 1.5 | R134a （HFC） | Rc3/8 | Less than 7.5kw |
| IDF3E | 35℃ 0.7 MPa | 0.32 | 0.37 | 2.2 | R134a （HFC） | Rc3/8 | Less than 7.5kw |
| IDF4E | 35℃ 0.7 MPa | 0.52 | 0.57 | 3.7 | R134a （HFC） | Rc1/2 | Less than 7.5kw |
| IDF6E | 35℃ 0.7 MPa | 0.75 | 0.82 | 5.5 | R134a （HFC） | Rc3/4 | Less than 7.5kw |
| IDF8E | 35℃ 0.7 MPa | 1.22 | 1.32 | 7.5 | R134a （HFC） | Rc3/4 | Less than 7.5kw |
| IDF11E | 35℃ 0.7 MPa | 1.65 | 1.82 | 11 | R134a （HFC） | Rc3/4 | Less than 7.5kw |
| IDF15E1 | 35℃ 0.7 MPa | 2.8 | 3.1 | 15 | R134a （HFC） | Rc1 | Less than 7.5kw |
| IDF100F | 40℃ 0.7 MPa | 16.0 | 18.8 | 100 | R407C （HFC） | R2 | Less than 7.5kw |
| IDF125F | 40℃ 0.7 MPa | 20.1 | 23.7 | 125 | R407C （HFC） | 65（2 1/2B） flange | Less than 7.5kw |
| IDF150F | 40℃ 0.7 MPa | 25.0 | 30.0 | 150 | R407C （HFC） | 80（3B） flange | Less than 7.5kw |
| IDF190D | 40℃ 0.7 MPa | 32.0 | 38.0 | 190 | R407C （HFC） | 80（3B） flange | Less than 7.5kw |
| IDF240D | 40℃ 0.7 MPa | 43.0 | 50.0 | 240 | R407C （HFC） | 100（4B） flange | Less than 7.5kw |
| IDF370D | 35℃ 0.7 MPa | 54.0 | 65.0 | 370 | R407C （HFC） | 150（6B） flange | More than 7.5kw |
Refrigerated Air Dryer IDU □E
Air Preparation Equipment » Air Dryers
Safety Instructions Air Preparation Equipment/Precautions
Model Selection Guide/Quick Reference Guide Green Procurement (RoHS) Proposal for the Use of a Separate Refrigerated Air Dryer
Model Selection Guide/Quick Reference Guide Green Procurement (RoHS) Proposal for the Use of a Separate Refrigerated Air Dryer
| Series | Rated inlet condition | Air flow capacity (m3/min[ANR]) 50 Hz | Air flow capacity (m3/min[ANR]) 60 Hz | Applicable air compressor (kW) | Refrigerant | Port size | Compressor output |
|---|---|---|---|---|---|---|---|
| IDU3E | 55℃ 0.7 MPa | 0.32 | 0.37 | 2.2 | R134a （HFC） | Rc3/8 | Less than 7.5kw |
| IDU4E | 55℃ 0.7 MPa | 0.52 | 0.57 | 3.7 | R134a （HFC） | Rc1/2 | Less than 7.5kw |
| IDU6E | 55℃ 0.7 MPa | 0.75 | 0.82 | 5.5 | R134a （HFC） | Rc3/4 | Less than 7.5kw |
| IDU8E | 55℃ 0.7 MPa | 1.1 | 1.2 | 7.5 | R134a （HFC） | Rc3/4 | Less than 7.5kw |
| IDU11E | 55℃ 0.7 MPa | 1.5 | 1.7 | 11 | R134a （HFC） | Rc3/4 | Less than 7.5kw |
| IDU15E1 | 55℃ 0.7 MPa | 2.6 | 2.8 | 15 | R134a （HFC） | Rc1 | Less than 7.5kw |
| IDU22E | 55℃ 0.7 MPa | 3.9 | 4.3 | 22 | R407C （HFC） | R1 | Less than 7.5kw |
| IDU37E | 55℃ 0.7 MPa | 5.7 | 6.1 | 37 | R407C （HFC） | R1 1/2 | Less than 7.5kw |
| IDU55E | 55℃ 0.7 MPa | 8.4 | 9.8 | 55 | R407C （HFC） | R2 | Less than 7.5kw |
| IDU75E | 55℃ 0.7 MPa | 11.0 | 12.5 | 75 | R407C （HFC） | R2 | Less than 7.5kw |
Refrigerated Air Dryer/Double Energy Saving Function Series IDF100FS/125FS/150FS
Air Preparation Equipment » Air Dryers
-
・Energy-saving design (Second re-heater + Digital scroll compressor)
・Power consumption: Reduced by up to 76%
・Exhaust heat: Reduced by up to 25%
・Tolerant of high temperature environments!
・Ambient temperature: Up to 45ºC, Inlet air temperature: Up to 60ºC
Safety Instructions Air Preparation Equipment/Precautions
Model Selection Guide/Quick Reference Guide Green Procurement (RoHS)
Model Selection Guide/Quick Reference Guide Green Procurement (RoHS)
| Series | Applicable compressor (kW) | Air flow capacity （m3/min［ANR］） 50 Hz | Air flow capacity （m3/min［ANR］） 60 Hz |
|---|---|---|---|
| IDF100FS | 100 | 16 | 18.8 |
| IDF125FS | 125 | 20.1 | 23.7 |
| IDF150FS | 150 | 25 | 27 |
Refrigerated Air Dryer/For Use in Southeast Asia IDFC□
Air Preparation Equipment » Air Dryers
-
・Applicable for the high-temperature environments of tropical regions
・Can be used in high-temperature environments
Ambient temperature : Max. 45℃
Inlet air temperature : Max. 80℃
Dew point range : 3℃ to 20℃
・Air flow capacity : 9.2 m3/min (52% increase compared to the current model)
・Power supply voltage : Single-phase 230 VAC (50 Hz)
Safety Instructions Air Preparation Equipment/Precautions
Model Selection Guide/Quick Reference Guide Green Procurement (RoHS)
Model Selection Guide/Quick Reference Guide Green Procurement (RoHS)
| Series | Rated inlet condition | Air flow capacity (m3/min [ANR] ) Outlet air pressure dew point 3℃ | Air flow capacity (m3/min [ANR] ) Outlet air pressure dew point 10℃ | Air flow capacity (m3/min [ANR] ) Outlet air pressure dew point 20℃ | Refrigerant | Port size |
|---|---|---|---|---|---|---|
| IDFC60 | 50℃ 0.7 MPa | 0.9 | 2.8 | 4.7 | R410A(HFC) GWP：2088 | R1 |
| IDFC70 | 50℃ 0.7 MPa | 1.6 | 4.7 | 7.8 | R410A(HFC) GWP：2088 | R1 1/2 |
| IDFC80 | 50℃ 0.7 MPa | 2.2 | 6.5 | 10.9 | R410A(HFC) GWP：2088 | R2 |
| IDFC90 | 50℃ 0.7 MPa | 3.1 | 9.2 | 15.4 | R410A(HFC) GWP：2088 | R2 |
Refrigerated Air Dryer/For Use in North, Central, and South America IDFB□E
Air Preparation Equipment » Air Dryers
-
・Low GWP Refrigerant [New]
・UL, CSA certified product
・Power supply voltage: Single-phase 115 VAC (60 Hz), 230 VAC (60 Hz)
3-phase 460 VAC (60 Hz)
Note) The air flow capacity for each dew point is indicated.
∗ The IDFB22E/37E series has been discontinued in August 2019.
Please select the IDFB60/70 series.
Safety Instructions Air Preparation Equipment/Precautions Model Selection Guide/Quick Reference Guide Green Procurement (RoHS)
| Series | Rated inlet condition | Air flow capacity SCFM (m3/h [ANR] ) Outlet air pressure dew point Note) 37ºF（2.8℃） | Air flow capacity SCFM (m3/h [ANR] ) Outlet air pressure dew point Note) 45ºF（7.2℃） | Air flow capacity SCFM (m3/h [ANR] ) Outlet air pressure dew point Note) 50ºF（10℃） | Refrigerant | Port size |
|---|---|---|---|---|---|---|
| IDFB3E | 100ºF （37.8℃） 100 psi （0.7 MPa） | 10（17） | 11（19） | 12（20） | Standard: R134a (HFC) Low GWP Refrigerant: R1234yf (HFO) | NPT3/8 |
| IDFB4E | 100ºF （37.8℃） 100 psi （0.7 MPa） | 15（25） | 16（27） | 17（28） | Standard: R134a (HFC) Low GWP Refrigerant: R1234yf (HFO） | NPT1/2 |
| IDFB6E | 100ºF （37.8℃） 100 psi （0.7 MPa） | 25（43） | 26（45） | 28（47） | Standard: R134a (HFC) Low GWP Refrigerant: R1234yf (HFO) | NPT3/4 |
| IDFB8E | 100ºF （37.8℃） 100 psi （0.7 MPa） | 41（70） | 43（74） | 45（77） | Standard: R134a (HFC) Low GWP Refrigerant: R1234yf (HFO） | NPT3/4 |
| IDFB11E | 100ºF （37.8℃） 100 psi （0.7 MPa） | 59（100） | 62（106） | 65（110） | Standard: R134a (HFC) Low GWP Refrigerant: R1234yf (HFO) | NPT3/4 |
| IDFB15E | 100ºF （37.8℃） 100 psi （0.7 MPa） | 71（120） | 80（136） | 86（147） | Standard: R134a (HFC) Low GWP Refrigerant: R1234yf (HFO) | NPT1 |
| IDFB55E | 100ºF （37.8℃） 100 psi （0.7 MPa） | 226（384） | 258（438） | 297（504） | Standard: R407C (HFC) | NPT2 |
| IDFB75E | 100ºF （37.8℃） 100 psi （0.7 MPa） | 300（510） | 353（600） | 406（690） | Standard: R407C (HFC) | NPT2 |
Thermo-dryer with Air Temperature Adjustment Function IDH□
Air Preparation Equipment » Air DryersTemperature Control Equipment » Air Temperature Controllers
-
・Stable supply of temperature and pressure controlled dry clean air
Can supply compressed air with the same conditions and quality
regardless of the season
・Application example:
Supplying compressed air with constant conditions to air bearings
mounted on a tool
・Built-in filter
Nominal filtration: 0.01 μm (99.9% filtration efficiency)
Outlet oil mist concentration: Max. 0.01 mg/m3 (ANR)
Outlet cleanliness: Particles of 0.3 μm or more: 3.5 particles/L (ANR)
or less
・Compatible with power supplies from around the world Single-phase
100, 200, 230 VAC (50/60 Hz)
Safety Instructions Air Preparation Equipment/Precautions
Model Selection Guide/Quick Reference Guide Green Procurement (RoHS)
Model Selection Guide/Quick Reference Guide Green Procurement (RoHS)
| Series | Air flow capacity L/min（ANR） | Outlet air temperature adjustment range | Outlet air set pressure range | Outlet air temperature stability | Cooling method | Compressor output |
|---|---|---|---|---|---|---|
| IDH□4 | 100 to 500 | 15 to 30℃ | 0.15 to 0.85 MPa | ±0.1 | Heater operation PID control | Less than 7.5kw |
| IDH□6 | 200 to 800 | 15 to 30℃ | 0.15 to 0.85 MPa | ±0.1 | Heater operation PID control | Less than 7.5kw |
Heatless Air Dryer ID
Air Preparation Equipment » Air Dryers
-
・Can supply dry air with a low dew point below –30ºC
・Compact and lightweight without a heater or an electric control board
・It is possible to check the outlet dew point with the indicator.
(Self-regenerative type allows for easy maintenance)
Safety Instructions Air Preparation Equipment/Precautions
Model Selection Guide/Quick Reference Guide Green Procurement (RoHS)
Model Selection Guide/Quick Reference Guide Green Procurement (RoHS)
| Series | Outlet flow L/min (ANR) | Inlet flow L/min (ANR) |
|---|---|---|
| ID | 80 to 780 | 100 to 975 |
Membrane Air Dryer IDG□A/IDG
Air Preparation Equipment » Air Dryers
-
・It is possible to easily supply dry air using the hollow fiber membrane.
・Non-fluorocarbon
・Power supply not required
・Compatible with low dew points (–60ºC)
・No vibration or heat discharge
・With a dew point indicator
Safety Instructions Air Preparation Equipment/Precautions
Model Selection Guide/Quick Reference Guide Green Procurement (RoHS)
Model Selection Guide/Quick Reference Guide Green Procurement (RoHS)
| Series | Outlet flow L/min (ANR) | Standard dew point (°C) |
|---|---|---|
| IDG□A/IDG | 10 to 1000 | －15，－20，－40，－60 |
Moisture Control Tube IDK
Air Preparation Equipment » Air DryersFittings and Tubing » Tubing(Fluoropolymer/Clean)
-
・Prevents condensation in piping for small cylinders/air grippers
・Diffuses water vapor in the piping to the outside
・All you have to do is install the moisture control tube.
Additional power supplies and works are not necessary.
| Series | O.D./I.D. (mm) | Effective length (mm) | Applicable fittings |
|---|---|---|---|
| IDK02 Linear shape | 2/1.2 | 100 200 | KQ2 |
| IDK04 Linear shape | 4/2.5 | 100 200 | KQ2 |
| IDK06 Linear shape | 6/4 | 100 200 | KQ2 |
| IDK04-100-C1 Coil shape | 4/2.5 | 100 | KQ2 |
